Database nr. | : | 00026 |
---|---|---|
Titel | : | Onbekleed geraamte van de nieuwe zuigmond van de RSL tunnel / Uncovered frame of the new inlet of the RSL tunnel |
Instituut | : | RSL |
Locatie | : | Amsterdam, Marinewerf |
Datering | : | ca. 1919 |
Bijzonderheden | : | De gemodificeerde inlaat tijdens de bouw. Hier is duidelijk te zien dat de oorspronkelijke inlaat (foto 00007) werd voorzien van een dikke klokvormige rand (de"bellmouth") om de stroming te verbeteren. Het resultaat daarvan is te zien in foto 00018. The modified inlet during the construction. Clearly visible is that the original inlet (photo 00007) is provided with a thick clock shaped edge (the "bellmouth") to improve the air inflow. The result can be seen at photo 00018. Zie ook foto's 00007, 00018, 00045 en 00363. |
Fotograaf | : | |
Collectienaam | : | RSL |
Rubriek | : | Aerodynamica |
Subrubriek | : | Windtunnels |
Categorie | : | |
Achterkant afbeelding | : | |
Afmetingen | : | L=17cm, B=23cm |
Rapportnummer | : | |
|
||
