Database nr. | : | 00143 |
---|---|---|
Titel | : | Druk meet apparatuur (meetruimte V-lab) / Pressure equipment calibration room (V-laboratory) |
Instituut | : | NLR |
Locatie | : | Amsterdam, Schinkel Industrieterrein |
Datering | : | ca. 1970 |
Bijzonderheden | : | Een foto van het druk-ijklaboratorium van de afdeling Instrumentatie Vliegproeven (VA) in de klimaatgeregelde ijkruimte in het oude sterkte(S)-laboratorium. Je ziet van links naar rechts een drukvat met meters die de onderdruk aangeven door de luchtpompen die buiten de ijkruimte zijn opgesteld. Daarnaast de bedienkast van de twee kwikkolommen rechts in het normaliter afgesloten kabinet. Naast de bedienkast de installatie om diverse drukinstrumenten tegelijk te kunnen ijken. Daarnaast een watermanometer om kleine drukverschillen te kunnen meten, On the picture the pressure calibration laboratory of the Instrumentation Flight testing (VA) department in the climate-controlled calibration room of the former strength(S)-laboratory. From left to right a pressure vessel with instruments that present the underpressure produced by the air pumps outside the calibration room. Next to the vessel is the control cabinet, that is normally closed and contains two mercury columns. Further to the right the facility to simulataneously calibrate various pressure instruments. Most to the right is a water manometer to measure small pressure differences. |
Fotograaf | : | |
Collectienaam | : | |
Rubriek | : | Luchtvaartuigen |
Subrubriek | : | Vliegproefinstrumentatie |
Categorie | : | Foto: z/w |
Achterkant afbeelding | : | Onbekend |
Afmetingen | : | L=13cm, B=18cm |
Rapportnummer | : | |
|
||
Record aangepast: 29 september 2020
